Fire Fighting Water Storage Tank, ASTM A36, SS 400, 100000 Gallons
Key Specifications / Features
Model No.: FAB-240131-LST-02
Hits: 3
As a leading fire protection water storage tank manufacturer, we specialize in designing and fabricating tanks compliant with API 650 and GB 50341 standards. Constructed from high-quality materials such as Q235B, ASTM A36, and SS 400, our tanks ensure robustness and longevity. With a fixed roof and vertical design, our tanks offer reliable fire protection solutions. They are available in various sizes, including options with a maximum volume of over 100,000 gallons, catering to diverse industrial and commercial needs.
Request a quote
Tags
Detail Information
Product Name: Fire Water Storage Tank
Media: Water
Standard: API 650, GB 50341
Sheel Material: Q235B, ASTM A36, SS 400 (Carbon Structural Steel)
Roof Material: Q235B, ASTM A36
Compression Ring Material: Q235B, ASTM A36
Bottom Plate Material: Q235B, ASTM A36
Earthing Lug Material: Stainless Steel 304 (SS 304).
Working Temperature(In/Out): 25℃
Design Temperature: 4℃ to 80℃
Volume: 400 m3/Approx. 105,669 Gallon
Design Pressure: -490 PaG to 20,000 PaG
Weight (Net Mass): Up to 23,730 kg
Weight (Mass of Full Water): Up to 423,730 KG
Description: Power Plant Gas Pipeline in Sudan
This fire protection tank is a water storage tank for fire protection, sometimes is called a fire water tank. Welded according to JB/T4709, this bulk water storage tank has a capacity more than 100,000 Gallons. The maximum capacity is about 105,669 Gallons.
With high quality and fixed roofs, FAB's fire water tanks are vertically installed above ground and purchased for a power plant's gas pipeline project in Sudan.
